• Open the chuck (6) by turning the chuck key
(10) counterclockwise.
• Insert the drill bit (12) into the chuck (6).
• Close the chuck (6) by turning the chuck key
(10) clockwise.
• Remove the chuck key (10) from the chuck (6).
Removing
• Place the chuck key (10) into one of the holes
in the chuck (6).
• Open the chuck (6) by turning the chuck key
(10) counterclockwise.
• Remove the drill bit (12) from the chuck (6).
• Close the chuck (6) by turning the chuck key
(10) clockwise.
• Remove the chuck key (10) from the chuck (6).
Mounting and removing the auxiliary grip (fig. C)
Mounting
• Loosen the auxiliary grip (8).
• Slide the auxiliary grip (8) over the chuck (6).
• Turn the auxiliary grip (8) to the required
position.
• Tighten the auxiliary grip (8).
Removing
• Loosen the auxiliary grip (8).
• Remove the auxiliary grip (8) from the chuck (6).
• Tighten the auxiliary grip (8).
Mounting and removing the depth stop (fig. D)
The depth stop is used to set the maximum
drilling depth.
• Insert the depth stop (9) through the hole in the
auxiliary grip (8).
• Set the depth stop (9) to the required position.
USE
Switching on and off (fig. A)
• To switch on the machine, press the on/off
switch (1). The further the on/off switch (1) is
pressed, the higher the speed of the machine.
• To switch the machine to continuous mode,
keep the on/off switch (1) pressed and
simultaneously press the lock-on button (2).
• To switch off continuous mode, press the on/
off switch (1) again.
• To switch off the machine, release the on/off
switch (1).
6
Forward/reverse switch (fig. A)
Do not change the direction of rotation
during use.
• For clockwise rotation, slide the forward/
reverse switch (4) to the left.
• For counterclockwise rotation, slide the
forward/reverse switch (4) to the right.
Setting the maximum drilling speed (fig. A)
Do not set the speed during use.
• Turn the speed adjustment wheel (3) clockwise
to increase the maximum drilling speed.
• Turn the speed adjustment wheel (3)
counterclockwise to decrease the maximum
drilling speed.
Setting the operating mode (fig. E)
Do not change the operating mode
during use.
• Set the switch (5) to position
• Set the switch (5) to position
drilling.
Hints for optimum use
• Clamp the workpiece.
• Firmly hold the machine with both hands.
• Place the drill bit on the workpiece.
• Switch on the machine.
• Do not apply too much pressure on the
machine. Let the machine do the work.
• Switch off the machine and wait for the
machine to come to a complete standstill
before putting the machine down.

CLEANING AND MAINTENANCE

Before cleaning and maintenance, always
switch off the machine and remove the
mains plug from the mains.
• Regularly clean the housing with a soft cloth.
• Keep the ventilation slots free from dust and
dirt. If necessary, use a soft, moist cloth to
remove dust and dirt from the ventilation slots.
for drilling.
for hammer
