8 Device Description
Construction
11
10
9
8
(Figure similar)
Pos. Description
1 Top tensioning nut (bronze)
2 Clamping plate
3 Product plate
4 Space for cassettes
5 Lower tensioning nut (bronze)
6 Base plate
7 Base pull rod
* Luer lock connection (female)
12 13
7 6
Pos. Description
8 Permeate outlet*
9 Feed inlet*
10 Permeate outlet*
11 Retentate outlet*
12 Top pull rod
13 PEEK plain washer
1
2
3
4
5
