Safety Considerations

Read all instructions before attempting to operate this
machine and save these instructions.
Warning! When using electric machines, basic safety
precuations should always be followed to reduce the
risk of fire, electric shock and personal injury,
including the following:
1. Work area environment
Don´t expose the machine for rain. Don´t use it
in damp or wet locations or in presence of
flammable liquids or gases.
2. Overload
Never let the machine operate fully throttled.
Always follow the regulations pertinent to the
material you are working with ie asbestos. Don´t
use the machine for purposes that it isn´t inten-
ded for.
3. Body injuries
Never let the suction come in contact with parts
of the body. The strong suction effect can hurt
the blood-vessels in the skin. Do not repair the
electric components yourself, get somebody
qualified. Faults may cause injury. See also
below under warnings.

TECHNICAL DATA

HxWxL
Weight
Inlet
Hose length
Collection sack
Flow, max
Neg. pressure, max
Power consumption
Degree of separation
pre-separator
Degree of separation
(DIN 24184/3)
fine filter
Fine filter polyester, area 1.8 m
Degree of separation
HEPA filter (DOP)
Filter area, HEPA filter
Soundlevel
1375 x 650 x 700 mm
54 kg
X 50 mm
5-20 m
2 x 30 l
3
320 m /h
21 kPa
2300 W
80-90%
99.9%
2
99.97 %
1.5 m 2
75 dB(A)
DC 3800c Twin - 8
4. Don´t abuse cord
Never pull the machine by cord. Keep cord
from heat and sharp edges. Check the electric
cable regularly if damage.
5. Important measure
With cleaning and maintenance on the machine,
the power cable should be dis-connected from
the supply.
6. Maintain the machine with care
Keep machine clean and check that the hose is
entired and that all gaskets are tight. Follow
instructions. Keep handles dry and free from oil
and grease.
7. Checking of damage
Before futher use of the machine it should be
carefully checked that the machine is un-
damaged. If there are any damaged parts these
should be repaired by of a Dustcontrol
authorized service center.
8. Warning
Use only accessories and replacable parts which
are available in Dustcontrol catalogue.
When using faulty parts or pirate parts (espe-
cially filter) the machine could leak out
unhealthy dust which can cause personal
injuries.
Capacity
kPa
20
DC 3800c Twin
10
100 200
3
300 400 m /h
Art Nr 9483
