AVG 0160
6.2

Technical Data

Suitable for inner cable diameters
Strip length
Max. Insulation O/D
Dimensions
Length
Width
Heigth
Weight
Tension
7

Transport and Installation

7.1

Transport

The weight of the Strip and Twist Machine AVG 0160 is approx. 6kg ( 13 lbs).
7.2

Installation

INFORMATION:
To reduce production noise or vibration the machine can be placed on an insulating
rubber mat.
ATTENTION!
Position the Strip and Twist Machine AVG 0160 on a flat surface and assure the
stability of the machine. Ensure that the table or bench is stable enough to support
the machine in normal use.
Assure an appropriate table height. The table height is depending on the position of
the operator (work in sitting or standing position) according to prEN 894-4:2004,
Table A.1.
The Strip and Twist Machine AVG 0160 does not have its own light source. Assure
an appropriate illumination of the working place. (EN 1837:1999 – chapter 4.2: "The
general value of illumination hast to be 500 lx [...]")
0,01-6,0 mm²
(AWG 24-10)
1,5 mm - 29 mm
Ø 5,70 mm
230 mm
140 mm
150 mm
5,650 kg
110 / 220 / 240 V/50Hz
