Temperature Measurement (T°); No Sensor; With Sensor - PCE Instruments F07 Bedienungsanleitung

Characteristics
Display range
Measuring range (1)
Accuracy
Resolution
Triggering threshold (2)
(1) Below 5 Hz, the display shows 0.0
(2) Below the triggering threshold, the display shows an
indeterminate value (- - - -).
In AC + DC mode ,the triggering threshold corresponds
to the AC component (AC) of the signal.
MIN/ MAX Mode:
- Accuracy: same as in the table above +0.2% of reading
with limitation to 5 kHz.
- Capture time: 125 ms typ. every 400 ms
3.9 Temperature Measurement (T°)

3.9.1 No sensor

Set the rotary switch to position "T°".
The temperature displayed is the internal temperature of the
unit (INT symbol ON), equivalent to the ambient temperature
after a sufficient period of thermal stabilisation. It can be
expressed in °C or °F: choice of a unit using the yellow key.

3.9.2 With sensor

1. Connect sensor (K couple) to the clamp terminals,
observing the polarity indicated and placing it where you
wish to measure the temperature.
2. Set the rotary switch to position "T°". The temperature
displayed is that of the sensor (EXT symbol ON), it may be
expressed in °C or °F: choice of unit by the yellow key.
Characteristics
Function
Type of sensor
Display range
Extended
measurement
Accuracy
Resolution
Detection of
sensor shutdown
Thermal
time
constant
Note: The accuracy announced for external temperature
measurement does not integrate the accuracy of the K couple.
40 Hz
10.00 to
39.99 Hz 399.9 Hz 3999 Hz 19.99 kHz
0.01 Hz
Internal temperature
Integrated Circuit
400°C
400°F
-10,0°C to
+50,0°C
+15,0°F to
+120,0°F
± 1,5°C
±2,7°F
-
0.7 min./°C
36
400 Hz 4000 Hz
40.0 to 400 to
0.4% L +1 pt
0.1 Hz 1 Hz
5 V or 10 A
External temperature
K Couple
400°C
400°F
-50,0°C to
+399,9°C
-50,0°F to
+399,9°F
1% L ±1,5°C
1% L ±2,7°F
0,1°C
0,2°F
INT symbol ON
instead of EXT
Depending on sensor model
40 kHz
4.00 kHz to
10 Hz
4000°C
4000°F
+400°C to
+1.000°C
+400°F to
+1832°F
1% L ±1,5°C
1% L ±2,7°F
1°C
1°F
