Clamp multimeter F07 emphasises reliability and simplicity
of use to respond to the needs of power professionals:
A compact unit integrating the current sensor for intensity
measurements without breaking the test circuit
Outstanding ergonomic features, in particular:
- automatic or manual selection of the type of signal to be
measured, AC or DC,
- measurement of the RMS value of any signal (AC + DC)
- automatic selection of measurement calibre,
- programmable audio voltage indication: V-Live,
- «measurement range exceeded» indication,
- Backlighting of the digital display
- auto power off system,
- MIN - MAX – PEAK value recording function,
- correction of deviations in DC measurement (DC zero)
- automatic compensation of measurement cable
resistance (Ω zero).
Compliance with CEI electrical safety standards and CE
markings
Lightness and ruggedness for field use
With all new additional features:
"Inrush" function in particular for measurement of motor
starting currents.
"Adapter" function with direct reading via scale factor
programming.
(see diagram in § 8 Appendix)
Jaws
6-way rotary switch:
OFF Deactivation of the clamp, activation is ensured by
selection of other functions
V Measurement of DC and AC voltages (rms value)
Continuity measurement, by use of the yellow
resistance key and semi-conductor test
A Measurement of DC and AC voltages (rms value)
T° Measurement of clamp ambient or external
temperature, depending on presence or absence
of sensor, in °C or °F.
Adp. Selection of «Adapter» function

1. PRESENTATION

2. DESCRIPTION
