AP05-SW04+SW05
8 Commissioning
• Pressing the key enables or disables the incremental measurement
function.
• Pressing the key starts calibration (see User manual).
• Pressing the key starts the configuration mode (see User manual).
LED Position monitoring
In the basic state (factory setting), the LED display has the following
meaning.
Color State
LED green on
off
LED red on
off
Configuration
The required parameters are set in the configuration mode. On the 1st line
of the display, the parameter will be shown and on the 2nd line the res-
pective value will be displayed.
Press key for changing actual value and / or the blinking digit when
entering a multi-digit value.
The key serves for switching to the next digit in case of multi-digit
numbers.
By pressing the key, the set value is acknowledged and saved non-
volatilely. If no key is pressed, the configuration mode will be exited after
~30 s without saving the latest value displayed, i. e. the original value will
be maintained.
For a detailed description of the configuration parameters refer to the
User manual.
Calibration
Two steps are required for executing calibration:
1. Write the calibration value in the configuration mode or via the bus
interface (see User manual)
=> Position value = current measured value + calibration value + off-
set value
AP05-SW04+SW05 · Date 01.03.2018 · Art. No. 89533 · Mod. status 49/18
1
Description
Actual position value is within the programmed
position window.
Actual position value is outside the programmed
position window.
Actual position value is outside the programmed
position window.
Actual position value is within the programmed
position window.
English
