Troubleshooting

1. Light doesn't power up when Button 1 (on/off) is pressed
a) Is light head plug inserted all the way? Make sure plug is inserted fully and locking ring
turned clockwise
b) Is the battery charged up? Recharge battery fully.
2. Light comes on but flickers when Button 1 (on/off) is pressed
a) Incompatible battery fitted in SPOWER LED base unit- only use approved replacement bat-
teries
available through your point of purchase.
b) Battery to light head communication fault – press Button 1 off then on – If problem still persists
unplug the light head completely for 2 minutes then replace plug and retry.
3. The external battery charger won't recharge the battery
a) Is charger plug inserted all the way? Make sure plug is inserted fully and locking ring turned
clockwise.
b) Has battery been left completely flat for an extended period of time? Contact us.
4. The internal (Vepac) charger shows no LED indication for the charging process
a) Supply cable from vehicle is not connected or there is a poor connection – check supply and
connections from the DC power source.
b) Supply voltage is not high enough to trigger the charger to start – check supply voltage is 13
volts DC or higher (vehicle must be running with alternator charging the supplying battery).
Supply cable must be adequate size to prevent voltage drop from the supplying battery to the
SETO POWER LED charging lead.
c) The SETO POWER LED internal battery is not connected – battery has been left too long in
a dischar-
ged state, the battery will need replacing.
5. The internal (Vepac) charger LED shows a rapidly flashing amber
This is a fault indication, the charger has timed out after 18hours because it can't recharge the
battery – replace SETO POWER LED battery with approved type.

Conformance

CE Marked. This product has been tested and conforms to EN 61000-6-3 and 61000-6-4.

Optional Remote Control

Contains Transmitter Module FCC ID: 0A3MR24J40MA
This device complies with part 15 of the FCC rules. Operation is subject to the following two con-
ditions:
1) This device may not cause harmful interference, and
2) This device must accept any interference received, including interference that may cause
undesired operation.
25
