Operation – Advanced Features
To use the unit simply press the on button and the light will come on to 100% power/brightness and
is ready for use, the additional buttons listed below allow other features to be accessed.
Battery comms
Button 1 = on/off
Button 2 = Mode
Button 3 = Brightness
Button 4 = SELECT

Button 1

Used for switching the unit either ON or OFF. Note that after switching off allow a few seconds be-
fore switching back on to allow the system to shut down then restart as it checks its battery comms.

Button 2/3/4

Used to put the light into different profiles as listed above. Switch on the unit (button 1), select a
mode (button 2), then select brightness (button 3), and next select a channel (button 4) as required.
In addition you can mix and match modes between the two channels, for example you can switch
ON (button 1), select a brightness (button 3), select a channel (inner for example, button 4) then
select a mode (button 2, SOS second press). Next select a channel (button 4, outer for example),
then select a mode (button 2, flashing or static) then select the channel (button 4) to bring both
channels on to create different light options.
Pressing and holding the (brightness) button allows dimming up and down regardless of what
brightness mode the unit has been set at.
Flashing, SOS, Alternate flashing
(between inner and outer LED arrays)
100%, 125%, 8%, 25%, 50%, 75%
inner, outer, both inner and outer LED arrays
