SOS Mode

The unit may be set to flash the LED's in the SOS sequence if the need ever arises. To do this,
switch on, select the power level (brightness) you wish to use (8%, 25%, 50%, 75%, 100% or
125%). Next press the MODE button twice, pressing the SELECT button allows the inner outer or
both channels of LED's to be run.

Flashing Mode

The unit may be set to constantly flash the LED's to provide a warning signal to others. To select this
option first switch on, select a power level you wish to use ( 8%, 25%, 50%, 75%, 100% or 125%)
then press the MODE switch once, pressing the SELECT button allows the inner, outer or both
channels of LED's to be run.

Battery Status Indication

A low battery warning with cut off function is included with your SETO POWER LED to prevent
deep discharging the high performance cyclic SLA battery. Deep discharging can lead to premature
failure, inability to be recharged and / or poor duration.
The user is signalled to help pre warn of the amount of energy left in the battery able to run the
LED light in 3 ways: 3 colour LED, audible bleeper and flashing of the LED's on the main panel. As
the fully charged battery discharges the indicator LED (located next to the power on/off switch) will
show green.
As the battery discharges further this indicator LED will change from green through to amber, at this
point the unit will give an audible bleep and see a blink of the main LED's to signal another change
nearer to the end of lamp duration.
Finally the indicator LED will change from constant red to flashing red where upon the lamp bright-
ness will default from any of the power setting down to the 25% one, the beeper will then sound
every 30 seconds and at the time the main LED panel will blink once. This process will then continue
until the battery voltage falls to a point where the unit will then automatically switch off. This process
will give users adequate time to retreat to an area of safety without being left in the dark.
The light cannot be switched back on until the battery has been recharged to prevent deep dischar-
ge and possible irreversible damage to the battery.
