Optional Equipment

Additional height

The overall lamp head height can be lifted from 820mm-1800mm by using four of the quicklock
extension poles, which store conveniently in the base of the SETO POWER LED. Simply slot and
twist the poles together to create a quick extension pole system. With the in built stability legs this
creates a unique compact self-contained tripod system.

Onboard charging

With the optional in built charging system this gives the user the option of charging from a 12 or 24
volt DC vehicle system without the need for addition equipment in the vehicle or back at a perma-
nent site.
The unit has a bi-coloured LED to show the state of charging. At initial con-
nection to the 12-24V/DC supply the charge indication LED will flash twice
green then twice red in a self test process to show all is ok. A constant red
shows bulk charging where the majority of charge is fed into the battery,
when the red LED starts to flash this shows the battery is 80% charged,
when the LED turns to green the battery is then fully charged and ready for
use. The charger only needs a simple cable (included) from the vehicle to
any one of the two multifunction sockets on the rear of the SETO POWER
LED.
The charger also employs a ´vehicle battery protect system` which prevents over discharge
of the main supplying vehicle's battery. It detects when the ve-
hicle alternator has started to charge the primary battery
then starts to charge the SPOWER LED. Once the alter-
nator stops charging the vehicle battery the SPOWER LED
charger will continue until ot sees the voltage of the primary supplying battery fall to a point that
may cause the vehicle not to start and then terminates charge to the SETO POWER LED to pre-
vent further discharge. The onboard vepac charging system can also be configured to ignore the
vehicle battery protect system, please confirm this at point of ordering. This may be useful when a
permanent 12-24V/DC supply is available or where the supplying batteries have more than enough
capacity to cope with a full recharge of the SPOWER LED. In addition the built charger can measure
the battery's ambient temperature and adjust the charging profile to suit, this unique process makes
sure the battery is charged to full capacity even when used in temperatures outside of the ´normal`
25°C for 100% capacity.
