CONFIGURING THE PEDALS
Each of the 3 pedals features:
- A metal head (17) with several perforations
(9 for the accelerator – 6 for the brake – 6 for the clutch)
- A plastic head support (21) (between the head and the arm) with 4 perforations
- A metal pedal arm (22) with 4 perforations
CAUTION: To avoid any calibration problems, always disconnect the USB cable
from your steering wheel before adjusting the settings on your pedal set.
Adjusting the pedal HEIGHT
- Using the included 2.5 mm Allen key (20), loosen and remove the 2 screws holding the metal
head (17) and its support (21) in place.
- Once this is done, select the height of your choice and then replace and re-tighten the screws.
Low position
Examples with the accelerator pedal:
Medium position (default)
Number of possible height positions per pedal:
- 4 for the accelerator pedal
- 2 for the brake pedal
- 2 for the clutch pedal
7/17
High position Very high position
