OVERVIEW
INSTALLATION
Installing/Replacing the lamp
Before replacing the lamp, unplug mains lead and let the lamp cool down (approx. 5 minutes).
During the installation do not touch the glass-bulbs bare-handed! Please follow the lamp manufacturer's
notes!
Do not install lamps with a higher wattage! Lamps with a higher wattage generate temperatures the device
was not designed for. Damages caused by non-observance are not subject to warranty.
For the installation, you need one PAR-20 E-27 lamp with up to max. 75 W.
Procedure:
Step 1: Open the housing cover by pulling the extension spring.
Step 2: If replacing the lamp, remove the old lamp from the spot.
Step 3: Screw the new 230 V/75 W PAR-20 E-27 lamp into the lamp socket.
Step 4: Close the device.
The lamps need to be preheated in order to protect them. Please adjust the filament preheat of your dimming
pack so that the coiled filament glows slightly.
DANGER TO LIFE!
Only install the lamp with the device switched off!
Unplug from mains before!
CAUTION!
The lamp has to be replaced when it is damaged
or deformed due to the heat!
14/32
(1) Colour filter frame
(2) Tube
(3) Mounting-bracket
(4) Hole for safety rope
(5) Extension spring
(6) Housing cover
(7) Mounting bracket screws
(8) Clip-to-hold clamps
(9) Silicone cable
42103580_V_2_0.DOC
