Install the drive on the wall
See figure A on page 83.
Check the insulation of the input and motor cables and the
motor
Check the insulation of the input cable according to local regulations before
connecting it to the drive.
Check the insulation of the motor cable and motor when the cable is disconnected
from the drive, see figure
DA
each phase conductor and the Protective Earth conductor using a measuring voltage
of 1000 V DC. The insulation resistance of an ABB motor must exceed 100 Mohm
USA
(reference value at 25 °C or 77 °F). For the insulation resistance of other motors,
please consult the manufacturer's instructions. Note: Moisture inside the motor
DA
casing will reduce the insulation resistance. If moisture is suspected, dry the motor
and repeat the measurement.
DE
Connect the power cables
ES
See figures C,
FI
1. Undo the two mounting screws at the sides of the front cover.
2. Remove the cover by sliding it forward.
FR
3. Attach the residual voltage warning sticker in the local language to the control
IT
panel mounting platform.
4. Remove the rubber grommets from the lead-through plate for the cables to be
NL
connected.
PT
5. Fasten the cable conduits to the cable lead-through plate holes. Strip the cable
ends. Slide the cables through the connectors.
RU
6. Connect the grounding conductors to the grounding terminals.
SV
7. Connect the phase conductors of the input and motor cables. Tighten the screws.
8. Units with option +D150: Connect the brake resistor cable conductors to the R+
TR
and R- terminals.
CN
9. Install the control cable grounding shelf in the cable entry box.
10. Connect the motor cable at the motor end.
Connect the control cables
See figure G on page 84.
F on page 84. Measure the insulation resistance between
D and E on page 83 and 84.
