EN – Quick installation guide
This guide instructs briefly how to install the drive. For more detailed instructions,
engineering guide lines, technical data and complete safety instructions, see the
hardware manual (www.abb.com/drives: Select Document Library and search for
document number 3AUA0000078093 [English]).
Follow the safety instructions
WARNING! Ignoring the following instructions can cause physical injury or
death, or damage to the equipment:
• Only qualified electricians are allowed to install and maintain the drive.
• Never work on the drive, motor cable or motor when main power is applied.
After disconnecting the input power, always wait for 5 min to let the intermediate
circuit capacitors discharge before you start working on the drive, motor or
motor cable.
• Do not work on the control cables when power is applied to the drive or to the
external control circuits.
• Make sure that debris from borings and grindings does not enter the drive when
installing.
• Do not connect the drive to a voltage higher than what is marked on the type
designation label.
The floor material below the drive must be non-flammable.

Select the power cables

Size the power cables according to local regulations to carry the nominal current
given on the type designation label of your drive.
Typical power cable sizes are listed in table
sizing, see the hardware manual.

Ensure the cooling

See table B on page
allowed operating temperature range of the drive without derating is -15 to +40 °C.

Protect the drive and input power cable

See table B on page 79. Check that the operating time of the fuse is below 0.5
seconds.
79 for the losses and the cooling air flow through the drive. The
EN – Quick installation guide 3
J on page 82. For the conditions of the
3AUA0000085966 Rev F
