11.1 Trouble shooting errors
Error Cause Remedies
code
010 "Horn alarm elements" X- Repair if necessary and
dock test failed test again with X-dock
011 "LED alarm elements" X- Repair if necessary and
dock test failed test again with X-dock
012 "Vibration alarm elements" Repair if necessary and
X-dock test failed test again with X-dock
013 Parameter check failed Correct parameters and
test again with X-dock.
014 Instrument locked by X- Cancel X-dock lock
dock
100 Flash/EEprom write failed Contact Service
104 Flash check sum wrong Contact Service
105 Broken or missing O Replace O
2
sensor
106 Most recent settings Check settings and
restored recalibrate instrument
107 Self test failed Contact Service
108 Configuration not up-to- Reconfigure with the latest
date Dräger CC-Vision
software version
109 Configuration error Reconfigure instrument
161 Set operating time of the Set new operating time of
instrument expired the instrument
210 Zero-point/fresh air Perform zero-point/fresh
calibration failed air calibration
220 Span calibration failed Perform span calibration
221 Calibration interval Calibrate instrument
expired
240 Bump test failed Perform bump test or
calibration
241 Bump test interval expired Perform bump test or
calibration
Warnin Cause Remedies
g code
162 Set operating time of the Set new operating time of
instrument almost expired the instrument
222 Calibration interval Calibrate instrument
expired
242 Bump test interval expired Perform bump test or
calibration
6

12 Technical Specifications

12.1 General
Environmental Conditions
During operation
Conditions for
storage
Battery life
o
(typical at 25 C)
Intensity of alarm
Dimensions
(without clip)
sensor
2
Weight
Ingress protection IP 68
Approvals
12.2 Standard Configuration (Factory Settings)
1)
Bump test mode
Vibration alarm
1)
Bump test interval
1) 2)
Life signal
Turning the instrument off
Data logger interval
Operation timer
% COHB mode
1 May differ for customer-specific orders.
2 For measurements according to EN 45544 (CO, H
EN 50104 (O ) the life signal must be switched on.
2
temperature see see chapter 12.3 and
see chapter 12.4
700 to 1300 hPa
10 to 90 % relative humidity
o o
0 to 40 C 32 to 104 F
30 to 80 % relative humidity
24 hours of use per day,
1 minute alarm per day:
>5,500 hours, O : >2,700 hours
2
typical 90 dBA at 30 cm/1 ft.
64 x 84 x 20 mm (battery compartment
25 mm)
2.5 x 3.3 x 0.8 (battery compartment 1 in.)
106 g/3.8 oz.
(see "Notes on Approval" on page 267)
Quick bump test
Yes
Off
Off
1)
Always allowed
1 minute
Off
Off
S) or
2
