Description and Operation

The VORT PLENUM 6+1 is an air distribution system
that can be used in combination with systems and ap-
pliances for centralised ventilation and can be mounted
near extraction and/or outlet conduits.
•
A1; A2: Ø125 mm vent
•
B1; B2; B3; B4; B5; B6: Ø 80 mm vent
•
C : blanking plug
•
D: inspection cover
1

Installation

3
6
2
