Drill stand

Intended use

The product is designed for commercial drills and is
suitable for placing exactly defined holes at right-
angles into wood, metal and ceramic tiles. It is pos-
sible to mount the work-piece securely during
drilling. Consult the manufacturer's operating man-
ual before using the drill. The product is not in-
tended for commercial use.

Parts description

Drill stand:
Bolt
1
Lever arm
2
Drill holding fixture
3
Guide slot (4 x)
4
Drill hole (4 x)
5
Base plate
6
Pillar
7
Block
8
Slider
9
Locking screw
10
Drill depth gauge with indicator
11
Screw
12
Machine vice:
Machine vice
13
Long slot
14
Locking device
15
Quick-release button
16
Clamping jaw
17
Contents
1 Drill stand
1 Hexagon key
1 Machine vice
1 Operating instructions
Technical Data
Drill holding fixture for
clamping collar diameter: 43 mm
Drilling depth:
Dimensions:
Clamping jaw width:
Clamp width:

Safety notes

YOU SHOULD STORE ALL SAFETY INFORMATION
AND INSTRUCTIONS IN A SAFE PLACE IN
CASE YOU NEED TO REFER TO THEM AGAIN
IN THE FUTURE!
CAUTION! RISK OF INJURY! When work-
ing with hand-operated electrical tool, slipping
or loosening of the mounted work-piece can
cause severe injuries. Therefore, never work on
a mounted work-piece using a hand-operated
electrical tool.
CAUTION! RISK OF SHEARING OR
CRUSHING INJURY! There is the risk of
shearing or crushing injuries while working with
the drill stand.
CAUTION! RISK OF INJURY! Pay attention
to flying chippings and splinters. There is the
risk of injury.
Keep out of the reach of children. Store the
product out of the reach of children.
Check the product for damage before each
use. Please do not use this device if you find
that it is damaged in any way.
Check that the screws are tight before each use.
Use the product on a solid, level and intact
surface (e.g. a workbench).
Always disconnect the drill from the power
supply before making adjustments or work
breaks.
Wear protective gloves and safety goggles.
The drill stand must be mounted on a workbench
or a stable, tilt-free table, to ensure a safe work.
Use the drill holes in the base plate
5
to 60 mm steplessly
adjustable
155 x 505 x 225 mm
(W x H x D)
65 mm
65 mm
.
6
