Dimensions:
Model
Resin (ltr)
Width (mm) (W)
Depth (mm) (D)
Depth, incl. factory bypass (mm) (D)
Height (mm) (H)
Model
Resin (ltr)
Width (mm) (W) (1)
Depth (mm) (D)
Height (mm) (H)
(1) Based on 85 mm spacing
TECHNICAL DATA - PF-SOF1
25 50
264 311
282 311
371 376
1.059 ±10 1.394 ±10
2x25 2x50
613 707
405 410
1.059 ±10 1.394 ±10
Page 19
PF-SOF1-SIM
75
338
338
389
1.560 ±10 1.836 ±10
PF-SOF1-ALT / PF-SOF1-PRL
2x75
761
436
1.560 ±10 1.836 ±10
100 150
365 415
365 415
403 428
1.833 ±10
2x100 2x150
815 915
463 513
1.833 ±10
