PROGRAMMING INSTRUCTIONS -
CONFIGURATION PARAMETERS

Before entering the programming mode, make sure that
the appliance is in the service mode.

All configuration parameters on this appliance have
been pre-programmed in the factory, to offer optimal
performance in a wide range of applications and situations.
Nevertheless it may be necessary or desirable to change any
of these parameters, to further optimize the appliances
performance or to adapt it to the specific requirements of
the installation.
only for PF-SOF1-SIM & PF-SOF1,5-SIM
1. Press the scroll button and hold it for 5 sec until the
display shows:
System Check
2. Within 10 sec, press the up
show:
HardUnit:°f
 Press the up or down
unit. Make sure to also adjust/convert the exchange
capacity!
3. Press the scroll button again; the display will show:
ExCap:5.5°f M3/L
Press the up or down

exchange capacity per litre of resin.
4. Press the scroll button again; the display will show:
Resin:XXX liters
Press the up or down

of resin.
5. Press the scroll button again; the display will show:
Override: 7 days
Press the up or down

of days between regenerations.
6. Press the scroll button again; the display will show:
Cycle 1:
Press the up or down

of the regeneration cycle.
Press the scroll button again to advance to the next

regeneration cycle.
Cycle 1 Backwash
Cycle 2 Brine draw/slow rinse
Cycle 3 Fast rinse/brine tank refill (PF-SOF1)
Fast rinse (PF-SOF1,5)
Cycle 4 Brine tank refill (PF-SOF1,5)
ELECTRONIC CONTROL PANEL
button; the display will
button to set the hardness
button to set the
button to set the volume
button to set the number
XX min
button to set the length
7. Press the scroll
MTR:SNAP SENSOR
Press the up

water meter sensor.
8. Press the scroll
Regen:Dlyd/Immd
2:00
Press the up

regeneration mode:
 Dlyd/Immd: when the remaining capacity equals
the reserve capacity, a delayed regeneration at
the programmed time of regeneration is started;
however when the remaining capacity equals 0
before the programmed time of regeneration is
reached, an immediate regeneration is started.
 Immediate: when the remaining capacity equals
0, an immediate regeneration is started.
 Delayed: when the remaining capacity equals the
reserve capacity, a delayed regeneration at the
programmed time of regeneration is started.
9. Press the scroll
(only when the regeneration mode is set to 'Delayed' or
'Dlyd/Immd'):
Regen @
Press the up

regeneration.
10. Press the scroll
(only when the regeneration mode is set to 'Dlyd' or
'Dlyd/Immd'):
Rsrv
Press the up

capacity:
 Variable: the reserve capacity is calculated
automatically, based on the registered daily water
usage.
 Fxd: press the scroll
up
capacity to a fixed amount.
11. Press the scroll
Exit
 Press the up
program into
programming level.
Page 13
button again; the display will show:
or down button to set the type of
button again; the display will show:
or down button to set the
button again; the display will show
2:00
or down button to set the time of
button again; the display will show
Variable
or down button to set the reserve
button again and press the
or down button to set the reserve
button again; the display will show:
or down button to save the
the NOVRAM® and
EN - English
exit the
