Ferm ATM1036 Originalbetriebsanleitung Seite 3

masking tape. The paint or fluid to be sprayed
should be thoroughly mixed and free from lumps
or other particles. Many substances can be
sprayed with your spray gun, but always check
the manufacturers recommendations before
purchasing your paint.
To obtain the best results, keep your spray gun
level and parallel to the surface at all times.
Keep the nozzle 25 - 30 cm from the surface and
spray evenly from side to side or up and down. Do
not spray at an angle as this will lead to paint runs
on the surface. Use smooth and even strokes.
It is essential that the spray gun is cleaned
thoroughly after every use. Failure to clean it will
almost certainly result in blockages and it may
not operate when you next come to use it! The
guarantee does not cover cleaning a sprayer that
has not been properly cleaned by the user.
Tyre inflating gun with pressure gauge
First check de pressure of the object (use the
pressure gauge on the blow gun)
• Connect the coupling of the gun with the valve
of the object
• Read the pressure on the gauge:
• Pressure too high: press the button on the
left side to release air.
• Pressure too low: press the trigger to fill the
object till required pressure.
• Check pressure by releasing the trigger and
read the pressure gauge.
• Disconnect the tyre inflating gun.
Average pressure
Object pressure (psi)
Soccerball
Basketball
Volleyball
Lawn-tractor tyre
Air bed
Bicycle tyre
Check the service-manual of your car for
the correct tyre pressure of your car.
pressure (bar)
13 0.8
9 0.6
5 0.3
20 1.3
hard hard
75 5
Air blow gun
Always be aware of small particles which can
release and cause injury. Do not point the blow
gun towards yourself during cleaning activities.
Air engine cleaning gun
The air engine cleaning gun can be used for
spraying liquids. For example to maintain rust-
sensitive materials such as garden tools.
• Pour the liquid into the cup
• Connect the cup to the air engine cleaning gun
• The flow can be adjusted by rotating the
nozzle. The nozzle can be blocked with help of
the locknut.
• Always clean the gun after every use.
Troubleshooting
Spray gun does not spray / blow gun does not
blow
1. Check the valve, cylinder and needle of the
nozzle on blockage
2. Check the air hose on leakage
3. Check the air pressure
"Orange Skin" excessive fogging.
1. Incorrect solvent is used
Use correct solvent.
2. Spray gun too far from the surface.
Hold spray gun closer to the object.
3. Paint too thick
Thin the paint
Tyre inflating gun: no air flow
1. Check the air pressure
2. Check hose connector (connected correctly?)
3. Check the air hose on leakage
3
