AIR TOOL SET 5 PCS.
Contents:

1. Machine data

2. Safety instructions

3. Use
Read the safety and operating
instructions of the air tool set and the
compressor before using the appliance!
1. MACHINE DATA
Spray gun
Operating pressure
Nozzle diameter
Aluminium cup capacity
Weight
Tyre inflating gun with pressure gauge
Operating pressure
Length of hose
Weight
Air blow gun
Recommended pressure
Nozzle diameter
Weight
Air engine cleaning gun
Recommended pressure
Nozzle diameter
Aluminium nozzle length
Weight
5m pu hose
Type
Max. pressure
Coupler
Weight
2. SAFETY INSTRUCTIONS
Always read the user manual of the
compressor and of the objects and/or
materials you use.
• Avoid too high pressure
• Never blow or spray in direction of yourself or
2
others; this could cause serious injury.
• Keep bystanders and pets away
• Children and animals should be kept far away
from the area of operation of the machine.
• If you use the compressor to spray paint:
a) Do not work in enclosed spaces or near
naked flames.
b) Make sure that the environment in
which you will be working has dedicated
ventilation.
c) Protect your nose and mouth with a
dedicated mask
• If the compressor is no longer in use, always
take the plug out of the plug socket.
• Always make sure that compressed-air
4.5 - 6 bar
hoses are used for compressed air and which
1.5 mm
are characterised by a maximum pressure
400 cc
adjusted to that of the compressor. Do not try
0.55 kg
to repair the hose if it is damaged.
3. USE
0 - 8 bar
350 mm
0.40 kg
Only use the compressor with accessory in a
good ventilated area.
• Connect the PU hose between compressor
2 - 4 bar
and accessory
2.0 mm
• Slide the hose-coupler on the accessory until
0.15 kg
the coupler clicks. Now the hose is connected
correctly.
• To release the coupler, pull the outside ring
2 - 4 bar
backwards.
2.0 mm
255 mm
Spray gun
0.55 kg
Paint and solvents are very flammable. Therefore
check the following:
• Only spray in good ventilated areas
5 mm x 8 mm
• Use a spray-mask during spraying
8 bar
• Avoid open fire and smoking during spraying
Universal/DIN
• Do not spray in an area with a burning stove
0.25 kg
• Never spray with fuel of other flammable
products
• Wear safety goggles
To obtain the best results, it is important that you
prepare the surface to be sprayed and thin the
paint to the correct viscosity, before you operate
your spray gun. Always ensure that the surfaces
to be sprayed are free from dust, dirt and grease.
Make sure that you have masked the areas that
should not be sprayed, using a good quality
