Connection Plan - dusar DCP Montageanleitung

GB
a.
b.
CN1
CN5
J9
F1 CN6 CN2 J7 J6 J5 J4
L N OUT
a.
g.
9 4 2
9 8 5
j.
0
. 6 0
m i n
f.
h.
All dimensions are approximate
I
NSTALLATION AND
f. f.
a.
b.
2 0 0
c.
g.
C
ONNECTION
j.
d. d.
(a) Drain Ø 40-50
(b) Connection 1/2" hot (*angle bracket 1/2")
(c) Connection 1/2" cold (*angle bracket 1/2")
(d) Protection zone approx. 600 mm
(e) Shut-off cock min. 15 mm pipe connection *
(f) Master switch with pilot lamp 2-pin *
(g) Equipotential bonding min. 6 mm
(h) IP 65 mains connection socket *
(i) Flexible connection hose in accordance with DIN
(j) Optional side panel
(* not included in the scope of delivery)
