E
E - Seat frame backrest tube
F - Seat support frame
G - Seat pad with padding
14
1) Assemble base support front tube and
rear tube (fig.1.). Ensure the pop pins are
locked in place so the front and rear tubes
are secured.
Fig.2
2) Connect the swing control module wire
with the battery compartment wire. Place
the swing control module on the base
support tube.
IMPORTANT! Place extra wire into the wire
casing on the base support tube to avoid
the wire being crushed after swing control
module is in place. Ensure the pop pins are
securely locked in place and that the swing
control module cannot be separated from
the base support tube.
Fig.3
Electric Bouncer
I
H - Toy bar
I - Adjustable backrest moulding
J - AC/DC adapter
J
Fig.1
