HDMI_SPDIF Cable
(Optional)
A. black end
ASRock 4CoreDual-SATA2 Motherboard
C
B
A
B. white end (2-pin)
Please connect the black end (A)
of HDMI_SPDIF cable to the
HDMI_SPDIF header on the
motherboard. Then connect the
white end (B or C) of
HDMI_SPDIF cable to the
HDMI_SPDIF connector of HDMI
VGA card.
C. white end (3-pin)
2 1 2 1 2 1 2 1 2 1
