() Infra-red receiver REMOTE SENSOR
This sensor receives the infra-red signals from the remote control. Direct the remote con-
trol towards this sensor during use.
(4) PRESET EQ button
Press this button repeatedly in order to select the following sound settings:
Pop (green), Rock (red), Classic (orange) and FLAT (no colour).
(5) VOLUME control
Using this control, you can set the volume.
Whilst volume is changed, the indicator FUNCTION (2) indicates the volume level. After a short
period, the indicator returns to show the chosen audio input.
(6) EXTERNAL PROCESSOR button
Press this button in order to incorporate any equalizer or signal processor connected to
the EQ sockets into the signal path.
(7) MIC LEVEL control
This control allows you to set the volume for the microphone connected to the MIC (8)
connected.
(8) MIC socket
A dynamic microphone can be connected to this input.
(9) PHONO button
This button is for the selection on the phono input.
(10) CD button
This button is for the selection on the CD input.
(11) AV1/AV button
This button is for the selection on the AV1/AV2 input.
Both inputs, AV1 and AV2 can be selected by repeatedly pressing the AV1/AV2 (11) button.
› 1 x Press > AV1 selected > indicator FUNCTION (2) lights up green.
› 2 x Press > AV2 selected > indicator FUNCTION (2) lights up red.
44 Chapter 5 Operation
(1) TUNER button
This button is for the selection on the TUNER input.
(1) TAPE button
This button is for the selection on the TAPE input.
(14) TREBLE control
Using this control, you can adjust settings for high pitch tones Turn the control to the
right to increase the volume of high pitch tones, turn it to the left to decrease the volu-
me of these tones.
(15) BASS control
Using this control, you can adjust settings for low pitch tones Turn the control to the
right to increase the volume of low pitch tones, turn it to the left to decrease the volume
of these tones.
(16) MUTE key
Press this button to switch off the sound temporarilty, without changing volume set-
tings (e.g. in order to make a telephone call).
(17) PHONES connection
Here you can connect headphones.
The loud speakers will become silent as soon as headphones are connected to this socket.
(18) STANDBY indicator
The indicator lights up when the device is switches off by remote control and is thereby
placed in standby mode.

Audio source play back

› Check again that all connections are correct.
› Turn the volume control VOLUME (5) all the way to the left.
› Turn the TREBLE (14) control and BASS (15) control to a middle position.
› Switch on the signal sources such as CD players, cassette decks etc.
