Move the machine head upwards and the
turntable to the 0° position.
•
Tighten the locking screw (10) and the tighte-
ning screw (22).
•
Position the bottom saw blade cover (14) on
the turntable so that it engages behind the
stop rail (7).
•
Press the release button (1) and lower the
machine using the handle (2) until the bottom
saw blade guard (14) completely covers the
saw blade.
•
Press the saw table (16) down at the front and
press the safety pin (23) in at the same time.
•
When you press in the safety pin (23), this
activates the switch (4) for bench mode and
deactivates the switch for crosscut mode (3).
•
Undo the locking screws (15, 24) and lower
the saw table until the desired cutting height
is reached for the saw blade.
•
Tighten the two locking screws again.
•
The saw has now been set to bench mode.
5.3 Adjusting options for the saw in crosscut
mode (Fig. 1/2)
•
Undo the locking screw (10) approx. 2 turns
to adjust the turntable (8).
•
The turntable (8) has locking points at angles
of 0°, 15°, 22.5°, 30° and 45°. Once the turn-
table (8) is engaged, the setting must also be
secured by tightening the locking screw (10).
•
If different angle settings are required, the
turntable (8) may be secured in position using
only the locking screw (10).
•
Swing up the machine head.
•
When the tightening screw (22) is loosened,
you can tilt the machine head to the left by up
to 45°.
5.4 Precision adjustment of the stop for cros-
scut 90° (Fig. 1-3/9/10)
•
Lower the machine head and fasten in place
with the safety pin (23).
•
Slacken the tightening screw (22).
•
Place the angular stop (a) between the blade
(5) and the turntable (8).
•
Slacken the counternut (b) and adjust the ad-
justment screw (c) until the angle between the
blade (5) and the turntable (8) equals 90°.
•
Retighten the counternut (b) to secure this
setting.
5.5 Precision adjustment of the stop for miter
cut 45° (Fig. 1-3/11/12)
•
Lower the machine head and fasten in place
with the safety pin (23).
GB
•
•
•
•
•
5.6 Sawdust extraction (Fig. 13)
•
•
•
5.7 Changing the saw blade (Fig. 14-19)
Caution! Unplug the device from the mains
power.
Caution! Always wear gloves when handling
the saw blade.
•
•
•
•
•
•
•
•
www.sidirika-nikolaidi.gr
- 25 -
Fasten the turntable (8) in 0° position.
Undo the tightening screw (22) and use the
handle (2) to tilt the machine head to the left
until it coincides at 45°.
Place the 45° stop angle (f) between the bla-
de (5) and the turntable (8).
Slacken the counternut (d) and adjust the
adjustment screw (e) until the angle between
the blade (5) and the turntable (8) equals 45°.
Retighten the counternut (d) to secure this
setting.
The machine is equipped with an extractor
socket (32) and also with an extractor port
(31) which can be fastened to the top saw
blade guard.
This means that the machine can be connec-
ted to standard sawdust extractors.
Never use the equipment without the suction
function. Regularly check and clean the suc-
tion channels.
Set the saw to crosscut mode (see 5.2.1).
Undo the screw (g) on the lever (h).
Place the face spanner (21) on the outer
flange (35) and undo the saw blade screw by
turning it in a clockwise direction using the
Hexagon key.
Remove the saw blade (5) from the inner
flange
Thoroughly clean the motor shaft and flange
before you fit and secure the new saw blade.
Important! The cutting angle of the teeth and
the direction arrow on the saw blade must
coincide with the direction of the arrow on the
housing.
Caution! Retighten the lever (h) on the
housing using the screw (g). Check that the
saw blade guard closes automatically when
the machine head is moved upwards before
you start using the machine.
The splitter is pre-set at the factory. If you ad-
just the settings of the splitter, you must make
sure that there is a gap of 3-5 mm between
the teeth of the saw blade and the splitter and
that the splitter is securely tightened.
