3. Layout (Fig. 1)
1 Air intake cover
2 LED display
3 Timer button (Timer)
4 Automatic slat adjustment button (Swing)
5 Heat settings button
6 ON / OFF button
7 ON / OFF main switch
8 Air outlet flap
9 Remote control
3.1 Description of LED display (Fig. 3)
A) Temperature / Hour display
B) Degrees Celsius
C) Hour (if the timer has been selected)
D) Fan on
E) Automatic slat adjustment on
F) Timer on
G) Heat settings on

4. Intended use

The equipment is designed for heating enclosed
rooms.
The machine is to be used only for its prescribed
purpose. Any other use is deemed to be a case of
misuse. The user / operator and not the
manufacturer will be liable for any damage or injuries
of any kind caused as a result of this.
Please note that our equipment has not been
designed for use in commercial, trade or industrial
applications. Our warranty will be voided if the
machine is used in commercial, trade or industrial
businesses or for equivalent purposes.

5. Technical data:

Rated voltage:
Output:
Timer:
Protection type:
Mains lead:
3. Mounting on the wall (Fig. 2)
Read the safety instructions in section 1.
Important! Make sure that there are no electric
cables or other installations (for example water
pipes) near the drill holes. Ensure that the appliance
230 V ~ 50 Hz
2000 W (1000 W / 2000 W)
1 to 8 hours
3 x 1 mm 2 x 1800 mm
is firmly and horizontally fitted to the wall. You must
always ensure that a distance of at least 75 cm is
kept between the front side of the heater and other
objects.
Do not let hot air blow onto combustible objects; it is
imperative to observe a distance of 1 m.
Use only suitable fastening material. The supplied
dowels and screws are suitable for the following:
Concrete, natural stone with a dense structure, solid
brick, solid limestone bricks, solid lightweight
concrete bricks and aerated concrete.
Mark the position of the drilled holes (diameter
8 mm, height from the floor at least 202 cm) for
mounting the equipment on the wall.
Note: The drill holes are arranged 500 in apart
horizontally.
Then drill the holes, insert the dowels, insert the
screws and
The equipment is also secured to the wall using a
holder. Mark the hole (A), drill the hole (diameter 8
mm), insert the dowel and fasten the holder to the
wall with the screw provided.
7. Starting up
Important. Before using the equipment for the first
time, check that the voltage supply is the same as
the voltage details set out on the rating plate.
Read the safety regulations in section 1.
When the equipment is used for the first time or after
a long period of rest it may emit an odor for a short
time. This is not a fault.
The ON/OFF main switch (Fig. 3 / Item 7) is used to
disconnect the equipment completely from the mains
supply. Switch the main switch to ON first of all or to
OFF last of all when you no longer need the
equipment. After you have switched on the
equipment at the main switch, the current equipment
temperature will be displayed near the integral
temperature sensor. This will be the current room
temperature if the equipment is set to cool blow
IPX0
mode.
7.1 Function switch (Fig. 3):
All functions apart from the nominal room
temperature setting can be set using the
pushbuttons on the equipment as well as with the
remote control.
The remote control runs on 2 batteries type "AAA".
Make sure that the poles are not reversed when you
change the batteries. Used batteries must be
