Instruction CF-RF Room Thermostat with Infrared Floor Sensor

1. Functional Overview

Front - fig. 1
Up/down selector
Push button
Red LED (behind the cover)
InfraRed floor sensor
LED modes
Permanent light
No light
Slow flashing
Fast flashing
Back - fig. 2
Back plate
Back plate lock/unlock (turn 90°)
Screw hole for wall mounting
Battery placement
Screw and wall plug
Note: To activate batteries please remove enclosed strips
from batteries

2. Installation

Note:
• To activate batteries in the Room Thermostat, please
remove enclosed strips from the batteries.
• The assignment of the Room Thermostats to the Master
Controller should be within 1½ m distance
VI.UH.R2.1C
4
ON
OFF
Flashes
Flickers
Produced by Danfoss Floor Heating Hydronics 03.2007
