Assembly instructions for TT20RS
21: Mount the 4-5 nuts on the
locking brackets. Screw them
down as far as possible so that
the top soapstone lies down
against the soapstone and is
level.
MOUNTING THE SOAPSTONE IN THE COMBUSTION COMPARTMENT
23: Mount the 2 accompanying
gaskets on the bottom of the
soapstone. First clean the stone
where the gasket is to be adhe-
red to. Remove the plastic plug
in the bottom of the stove.
7
"Heat Storage Kit"
22: Mount the top soapstone.
24: Carefully mount the stone with the gasket side downward in the combustion compartment and
press the peg on the top down, so that it can fasten in the hole on the ribs, set it carefully in place.
25: Mount any form cut glass plate under the wood-burning stove.
UK
