Safety notes / Before first use / Using the jack
Check that no person or object is under the
vehicle before you lower it.
Lower the vehicle slowly.
Check that all parts have been assembled
and fitted properly and are undamaged.
Before each use check that the hydraulic
vehicle jack is working properly. Check the
screws and valves of the hydraulic vehicle
jack for correct seating and look out for
hydraulic oil leaks in particular.
Never use the hydraulic vehicle jack for
moving or loading a vehicle. Never use it to
lift a whole vehicle completely off the ground.
Make sure that no-one – especially a child
– is in the vehicle and that everyone is kept
at an adequate distance away from the vehicle
when the hydraulic vehicle jack is in use.
Never change the setting of the safety valve
. It has been set at the factory and must
8
not be adjusted. Stop using the product if
the safety valve setting is changed.
Before using the vehicle jack, the user must
be made familiar with the device by an ex-
perienced person. The pump force and the
transferred force are equal to approximately
350 N.
If the markings on the product are damaged
enough so as to be illegible then the vehicle
jack must not be used until the markings are
renewed.
No modifications may be carried out to the
hydraulic trolley jack. Any physical modifi-
cation of the device has an effect on the
safety of the device and its compliance with
EN 1494:2009-05.
The applied force when using the vehicle
jack must not exceed 350 N. The equates to
a force on the lever of approximately 35 kg.

Before first use

Distribution of the
hydraulic oil
With the release valve
lifting handle
1
6 GB/IE
66308_uls_Wagenheber_Content_LB3.indd 6
closed, insert the
5
into the lifting handle
socket . Use at least 6 firm pumping
6
movements to charge the hydraulic system
(move lifting handle
action distributes the hydraulic oil evenly.
Note: Check that the release valve
by inserting the lifting handle
turn it clockwise (see Fig. A). When you cannot
turn it any further, the release valve
Using the jack
Raising the vehicle
With the release valve
lifting handle into the lifting handle
1
socket .
6
Place the hydraulic vehicle jack under one
of the lifting positions as shown in the owner's
manual supplied by the vehicle manufacturer.
Ensure that the support plate
loaded. By moving the lifting handle
and down, raise the vehicle sufficiently to allow
you to insert axle stands under the vehicle
(see Fig. B).
Allow the vehicle to come down on to the
axle stands by slowly opening the release
valve by turning the lifting handle
5
anticlockwise.

Lowering the vehicle

DANGER TO LIFE! Check that no person
or object is under the vehicle before you
lower it.
First raise the vehicle slightly (as described
earlier) in order to be able to remove the
axle stands.
Turn the release valve
the vehicle lowers, but do not turn it to the
extent that it detaches or hydraulic oil leaks
from the release valve
CAUTION! Lower the vehicle slowly, oth-
erwise there is the danger of injury and
damage to the product or to the vehicle.
up and down). This
1
is closed
5
and trying to
1
is closed.
5
closed turn the
5
is centrally
3
up
1
1
anticlockwise until
5
.
5
