Hydraulic trolley jack

Introduction
These operating instructions form a
part of this product. Make yourself
familiar with all the operating instruc-
tions and safety advice for the product before
use. Use the product only as described and for
the indicated purpose. If you pass the product
on to anyone else, please ensure that you also
pass on all the documentation with it.

Proper use

The hydraulic vehicle jack is intended for raising
and lowering motor vehicles. Other uses or
modification of the hydraulic vehicle jack shall
be considered as improper use and may lead
to injury or damage. The manufacturer will not
accept liability for loss or damage arising from
improper use. The product is not intended for
commercial use.
Note: Reclose the release
use!
Description of parts
Lifting handle
1
Lifting arm
2
Support plate
3
Carrying handle
4
Release valve
5
Lifting handle socket
6
Cover
7
Relief valve
8

Technical data

Stroke:
Maximum load:
Hydraulic oil grade:
Hydraulic oil quantity: 115 ml
66308_uls_Wagenheber_Content_LB3.indd 5
valve after each
5
130–343 mm (no load)
130–325 cm (no load)
2000 kg
ISO VG 15
Introduction / Safety notes
Maximum
force on lever: 350 N
Included items
1 Hydraulic car jack
1 Operating instructions

Safety notes

DANGER! Follow the instructions below to
avoid the threat of loss of life, injury, or
damage to the product etc.
Always use axle stands and wheel chocks
in addition to your hydraulic vehicle jack.
Never work under a raised vehicle unless
you have taken additional safety precautions.
This is intended to prevent the vehicle from roll-
ing away, sliding off or overturning the jack.
Use the product on a solid, level surface
only. Using the product on an unstable or
uneven surface – such as a gravel surface
– may lead to the load slipping.
Ensure that you never exceed the
allowable (rated) load capacity.
2000
kg
The person operating the jack must observe
the jack and the load during all movements.
Never work under the raised load if it has
not been made secure by suitable means.
Do not allow the hydraulic vehicle jack to
be used by uninstructed or inexperienced
persons.
Before using the hydraulic vehicle jack take
precautions to prevent the vehicle from roll-
ing away. Put the handbrake on, place the
vehicle in gear (with automatic gearboxes
set to "P") and chock the wheels.
Even with safety measures in place always
remain alert and make a visual check that
the support plate
3
against the vehicle jacking point.
Make sure that no petrol, battery acid or
any other dangerous substance can flow out
of the vehicle when the vehicle is being lifted.
is firmly seated
GB/IE 5
