The trimmer shall be used to cut stems less than
(33mm) thick.
◾
Trim only in daylight or in good artificial light.
◾
Remove or disconnect battery before servicing,
cleaning, or removing material from the hedge trimmer.
◾
Do not wash with a hose; avoid getting water in motor
and electrical connections.
◾
When servicing use only identical replacement parts
listed in this manual. Use of parts which do not meet
the original equipment specifications may lead to
improper performance and compromised safety.
◾
Follow instructions for lubricating and changing
accessories.
◾
Keep handles dry, clean and free from oil and grease.
◾
Save these instructions. Refer to them frequently and
use them to instruct others who may use this tool. If
you loan this tool to someone else, also loan these
instructions to them to prevent misuse of the product
and possible injury.
SAVE THESE INSTRUCTIONS!

SPECIFICATIONS

Model
Voltage
High
No-Load Speed
Low
Blade Length
Cutting Capacity
Weight (without battery pack) 3.6 kg
Measured sound power
level L
WA
Sound pressure level at
operator's position L
PA
K=2.5 dB(A)
Guaranteed sound power level
L (according to 2000/14/EC)
WA
Front Handle 3.369 m/s
Vibration a
h
K=1.5 m/s
2
Rear Handle 1.876 m/s
◾
The declared vibration total value has been measured
in accordance with a standard test method and may be
used for comparing one tool with another;
◾
The declared vibration total value may also be used in
a preliminary assessment of exposure.
56 VOLT LITHIUM-ION CORDLESS HEDGE TRIMMER— HT5100E / HT6500E
HT5100E HT6500E
56 V 56 V
1600 /min 1600 /min
1400 /min 1400 /min
51 cm 65 cm
33 mm 33 mm
3,8 kg
90 dB(A) 91.45 dB(A)
K=1.55 dB(A) K=1.08 dB(A)
81.5 dB(A) 81.4 dB(A)
92 dB(A) 93 dB(A)
5.313 m/s
2 2
3.115 m/s
2 2
NOTICE:
The vibration emission during actual use of the
power tool can differ from the declared value in which the
tool is used; In order to protect the operator, user should wear
gloves and ear protectors in the actual conditions of use.

PACKING LIST

PART NAME
Hedge Trimmer
Shield
Operator's manual
DESCRIPTION
KNOW YOUR HEDGE TRIMMER (Fig. A)
1. Battery-release Button
2. Rear Handle
3. Lock-off Trigger
4. Rear Switch Lever
5. Speed Adjustment Knob
6. Front Handle
7. Front Switch Lever
8. Hand Guard
9. Blade Guard
10. Blade
11. Tip Protector
12. Latch
13. Electric Contacts
14. Mounting Slot
15. Ejection Mechanism
16. Lock for Handle
17. Motor Housing
18. Shield
WARNING: This product has been shipped
completely assembled. The hand guard shall never
be removed during use. Once damaged, replace it
immediately by a qualified service technician.
WARNING:
The safe use of this product requires an
understanding of the information on the tool and in this
operator's manual, as well as knowledge of the project
you are attempting. Before use of this product, familiarize
yourself with all operating features and safety rules.
EN
QUANTITY
1
1
1
