Teileliste - Maxxus MTX 6.2 Bedienungsanleitung

Teile-Nr. Bezeichnung
1 Base frame
2 Platform frame
3 Incline frame
4 Upright post
5 Console
6 Ezfit linking part
7 Motor base frame
8 Top motor bolt weldingM8 × 65
9 Hex full thread screw M8 × 75
10 Allen C.K.S half thread screwM10 × 80 × 40
11 Allen socket full thread screwM8 × 15
12 Allen socket full thread screwM8 × 75
13 Allen C.K.S full thread screwM8 × 15
14
Allen socket full thread screwM8 × 25
15 Allen C.K.S half thread screwM8 × 30 × 20
16 Allen C.K.S half thread screwM8 × 50 × 20
17 Allen C.K.S half thread screwM8 × 40 × 20
18
Allen C.K.S half thread screwM8 × 55 × 20
19 Allen C.K.S full thread screwM10 × 25
20 Allen C.K.S half thread screwM10 × 45 × 20
21 Allen C.K.S half thread screwM10 × 35 × 20
22
Allen counter sunk full thread screw M6 × 50 × Φ 16
23
Philips C.K.S full thread screwM5 × 10
24 Philips C.K.S full thread screwM4 × 10
25 Philips C.K.S self-tapping screwST4 × 16
26 Philips C.K.S self-tapping screwST4 × 20
27 Philips pan-head self-tapping screwST3 × 25
28 Philips counter sunk self-tapping screwST4 × 15
29 Philips pan-head self-tapping screwST3 × 10
30 Flat washer Φ 8
31 Flat washer Φ 10
32 Spring washer Φ 8
33
Lock washer Φ 5
34 Hex self-locking nut M8
35 Hex self-locking nut M10
36 Power metallurgy set Φ 17× Φ 10× 7
37
Spring
38 Magnetic ring
39 The whole console

Teileliste

25
Menge
1
1
1
2
1
1
1
1
1
2
2
3
8
2
5
3
2
4
2
1
1
6
6
7
11
8
4
12
6
14
3
4
1
8
3
2
1
1
1
