Teileliste - Maxxus MTX 7.2 Montageanleitung

Teile-Nr. Bezeichnung
Base frame
1
Platform frame
2
Incline frame
3
Upright frame (left)
4
Upright frame(right)
5
Console frame
6
Ezfit linking part
7
Motor base frame
8
Power line fixing sheet coated parts
9
Arm ring spray parts (left)
10
Arm ring spray parts (right)
11
Hex half thread screw M12 ×Φ 14 × 35× 19
12
Top motor bolt weldingM8 × 65
13
Hex full thread screw M8× 75
14
Allen socket full thread screwM8 × 15
15
Allen C.K.S full thread screwM8 × 15
16
Allensocketfull threadscrewM8 × 75
17
Allensocketfull threadscrewM8 × 40
18
Allen C.K.S half thread screwM10 × 35× 20
19
Allen c.K.S half thread screwM10 × 60× 20
20
Allen c.K.S half thread screwM8 × 40× 20
21
Allen c.K.S half thread screwM8 × 35× 20
22
Allen c.K.S half thread screwM8 × 30× 20
23
Allen counter sunk full thread screwM6 × 50×Φ 16
24
Philips C.K.S full thread screwM6 × 20
25
Philips C.K.S full thread screwM5 × 10
26
Philips C.K.S full thread screwM4 × 10
27
Philips C.K.S self-tapping screwST4 × 16
28
Philips C.K.S self-tapping screwST4 × 12
29
Philips pan-head self-tapping screwST3 × 25
30
Philips pan-head self-tapping screwST3 × 10
31
Philips counter sunk self-tapping screwST4 × 15
32
Flat washer Φ 8
33
Flat washer Φ 10
34
Flat washer Φ 14
35
Spring washer Φ 8
36
Lock washer Φ 5
37
Hex self-locking nut M8
38
Hex self-locking nut M10
39

Teileliste

26
Menge
1
1
1
1
1
1
1
1
1
1
1
2
1
1
2
14
3
4
3
1
3
2
5
6
6
6
6
12
9
4
2
12
11
3
2
2
1
6
3
