Technical specifications

Visible laser diode
Laser class
Work area (Ø) *
Precision *
Self-levelling range
Power supply
Operating duration
Temperature range
– for operation
– for storage
Weight (with batteries)
* When used with a laser detector (optional).
Instructions for use
The most important operating steps are
ALC 1-360
explained at the end of these instructions
on the illustrated pages.
630–650 nm
See from page 143.
2
The laser detector LR 1 can be used to expand
the application options.
60 m

Checking precision

< 3 mm/30 m
± 8 °C
It is recommended to check the device regularly
to ensure that it is always precise.
3 x LR20/D
If the precision deviates from the permitted
tolerance range, the device must be taken
≤ 35 h
to a customer service workshop authorised
by the manufacturer.
Have the device adjusted by authorised
–18 °C–49 °C
technicians only.
–28 °C–54 °C
The steps required to check the precision
0.88 kg
are explained at the end of these instructions
on the illustrated pages.
See from page 149.
FLEX ALC 1–360
13
