CORDLESS IMPACT DRIVER
PDSSA 20-Li A1

Introduction

Congratulations on the purchase of your new appli-
ance. You have chosen a high-quality product. The
operating instructions are part of this product. They
contain important information about safety, usage
and disposal. Before using the product, please
familiarise yourself with all operating and safety
instructions. Use the product only as described and
for the range of applications specified. Please also
pass these operating instructions on to any future
owner.

Intended use

This appliance is intended for screwing in and
unscrewing screws as well as for tightening and
loosening nuts. The appliance has clockwise/
anticlockwise rotation, a 1/4" hexagon socket bit
holder and an LED working light. The light on this
appliance is intended to illuminate the immediate
work area of the appliance. The rotary impact
function of the appliance enables the power of the
motor to be converted into uniform rotary impacts.
The impact mechanism comes into effect during
tightening and loosening.
The appliance is designed for use by adults. Young
people under 16 years of age may only use the
appliance under supervision. The manufacturer ac-
cepts no liability for damages caused by improper
use or incorrect operation of the appliance.
Use this product only as described and for the
areas of applications specified. The appliance is
not intended for commercial use. Any other usage
or modification of the appliance is deemed to be
improper and carries a significant risk of accidents.
The manufacturer accepts no responsibility for
damage(s) attributable to misuse.
│ GB │ IE │ NI │ CY
■ 2

Features

Tool holder
Locking sleeve
Bit holder (magnetic)
Rotation direction switch/lock
Belt clip
Battery charge level button
Battery display LED
Battery pack*
Release button for battery pack
LED work light
ON/OFF switch / Speed control
Adapter to 1/4" square
Bit holder
High-speed charger*
Red charge control LED
Green charge control LED

Package contents

1 cordless impact driver PDSSA 20-Li A1
1 adapter to 1/4" square
1 1/4" extension (50 mm)
1 belt clip
1 carrying case
1 set of operating instructions

Technical data

Cordless impact driver:
PDSSA 20-Li A1
Rated voltage:
Idle speed:
Rated stroke rate:
Max. torque:
Suitable for
metal screws:
Suitable for
wood screws:
Tool holder:
Use only the following battery to operate the
cordless tool: PAP 20 A1*
Type:
Rated voltage:
Capacity:
Cells:
20 V (DC)
0–2800 rpm
0–3600 ipm
180 Nm
≤ M8
≤ 8 mm Ø
1/4"
LITHIUM ION
20 V (DC)
2 Ah
5
