Teil-Nr. Bezeichnung
1
Main Frame
2
Plastic fan with sensor magnet
3
Pulling strap transmission set
4
Strap wheel set
5
Handlebar
6R
Handlebar cover, right
6L
Handlebar cover, right
7
Handlebar hook holder
8
Tension bracket & eyebolt set I
9
Tension bracket & eyebolt set II
10
Bolt for computer M5x10 mm
11
Nut 3/8"
12
Belt 350J6
13
DC Motor
14R
Cover, right
14L
Cover, left
15
Handlebar cover
16
Adjustable footplate
17R
Lower foot pedal, right
17L
Lower foot pedal, left
18
Round cap
Front stabilizer end cap with
19
transportation wheel
20
Pedal pad
21
Pedal strap
22
Shaft bracket
23
Shaft bushing Ø21,5x12mm
24
Aluminum beam
Hexagon Socket Countersunk Head
25
cap bolt 10x16
26
Bumper Stopper 28x28x37
Hexagon Socket Countersunk Head
27
cap bolt M8x80 mm
28
Aluminum beam cover
29
Rear connect plate
30
Rear stabilizer
31
Rear stabilizer end cap
32
Computer post
33
Computer post bushing Ø38-3/8"
34A
Lock pin ball
34B
Lock pin Ø15x80mm
34C
Nut
Teileliste
Menge Teil-Nr. Bezeichnung
1
34E
Lock pin shaft
1
35
Foot pedal button
1
36
Foot pedal button plate
1
37
Computer bracket
1
38
Computer UT-6911-1
1
39
Seat carriage
1
40
Seat
2
41
Hexagon Socket Head bolt M8x16mm
2
42
Seat roller
2
43
Spacer Ø8xØ12x11
Hexagon Socket Head bolt M8x35mm
4
44
2
45
Nylon nut M8
1
46
Carriage stop
1
47
Handlebar foam grip HDRØ30x3Tx215mm
1
48
Handlebar End cap Ø1 1/4"
1
49
Bolt cap Ø42
1
50
Power supply cable
2
51
Adapter
1
52
Sensor wire, 400mm
1
53
Computer wire, 400mm
2
54
Hexagon Socket Head bolt M5x10mm
2
55
Hexagon head bolt M6x60mm
2
56
Foot pedal connection plate
2
57
Nylon Locknut M6
1
58
Nylon Locknut 3/8"
Hexagon Socket Countersunk Head
2
59
cap bolt 3/8"x3 3/4"
1
60
Hexagon Head bolt 3/8"x4"
Hexagon Socket Head bolt
2
61
M6x10mm
4
62
Flat washer M8xØ16x1.5T
2
63
Self tapping screw 5/32"x1/2"
1
64
Self tapping screw 3/16"x5/8"
1
65
Self tapping screw 3/16"x1/2"
1
66
Plastic washer Ø32,45xØ38,5x2T
2
67
Cross head bolt M5x15
1
68
Hexagon head bolt M6x90mm
Hexagon Socket Countersunk Head
4
69
cap bolt M8x25 mm
Hexagon Socket Countersunk Head
1
70
cap bolt M8x25 mm
1
71
Self tapping screw M4x8 mm
1
27
Menge
1
2
2
1
1
1
1
14
6
6
6
8
4
2
2
2
1
1
1
1
4
2
1
3
2
1
1
1
6
6
6
6
2
4
1
2
4
8
