WolfVision VZ-8plus Bedienungsanleitung Seite 3

9
2 2
3
6
5
Connectors (3):
11 External input for Computers (see page 9)
13 RGBHV output (switchable)
15 PAL/NTSC Composite video output
17 Serial control input RS232 (see page 10)
19 DC-output for lightbox
Setting up
Power-on preset:
The power-on preset is automatically activated when switching on the unit. The settings are:
Zoom size approx. 20 x 15 cm (A5), Autofocus on, Autoiris on.
10
1 1
1 1
7
8
4
EXTERN IN DVI
7
11 12
1. Pull the arm upwards using the special pull ring (#8)
2. Turn the camera head (#1) and point it at the working surface
3. Connect the power adaptor to the DC-input (#18).
4. Connect your output unit (projector, monitor, video conferencing
unit etc.) to the appropriate output of the Visualier (#12, #13, #14,
#15 or #16).
IMPORTANT:
For choosing the right output please read the detailled
description on page 5!
5. Switch on the Visualizer with the power switch (#5)
ENGLISH
1 Camera head
2 Light
3 Connectors (on the back
as shown below)
4 Working surface
5 Power on/off key
6 Light key (Also works as White
Balance key if pressed for 3
seconds - see page 7)
7 Close up lens for camera
8 Pull ring
9 Auto focus on/off key
(a light above this key shows
that the auto focus is on)
10 Zoom keys
SVGA/XGA/SXGA Y/C VIDEO
13 14 15
12 DVI output (see page 10)
14 PAL/NTSC Y/C (S-Video) output
16 USB-port (see page 8)
18 Power connection 12V
3
USB RS 232 POWER LB
16
17 18 19
