Additional Information regarding Anti-theft Device
Anti-theft Device 1: T-bar lock
The Visiualizer can be fixed with a
can not be stolen. Follow the instructions from the cable lock manual.
Anti-theft Device 2: table lock bolt
table
(sectional view)
115
[4 "]
1 /
2
Printed in Austria, October 2012
security cable T-bar lock (Kensington Lock)
washer 6.4/17x3
washer 6.4/12x1.6
screw M6x35 or
screw M6x50
The Visualizer can also be fixed onto a table with the
supplied table lock bolt in order to minimize the risk of theft.
Please note that the usable depth of thread is 8mm, do not
screw in more than this.
Supplied accessories:
Socket head cap wrench 5mm
Screw DIN 912, M6x35 Zn
Screw DIN 912, M6x50 Zn
Washer DIN 125A 6.4/12x1.6
Washer DIN 7349 6.4/17x3
Assembly instructions VZ-8
