OVERVIEW

Front

Rear

6 7
Safety rope
ON OFF
Strobe
Strobe
Fuse:
F 0.5 A, 250 V
USE ONLY WITH A 250V FUSE
Power supply:
100 - 240 V AC, 50/60 Hz ~
10
1 2 3
4 5
8 9
Auto Sound
Speed
Sensitivity
Mic
LED D-25 Beam Effect
No. 51918664, EAN 4026397530308
10 0-240V 50/60Hz ~ 24 W F0.5 A,250V
T =45°C T =60°C 0.1m
a C
Steinigke Showtechnic GmbH Andreas-Bauer-Str. 5
97297 Waldbuttelbrunn Germany www.steinigke.de
11 12 13
1. Mounting bracket and hole for mounting
clamp
2. Fixation screw
3. Ventilation slots
4. Housing
5. Lens
13/16
6. Strobe Mode switch
7. Safety eyelet
8. Speed rotary control
9. Auto/Sound Mode switch
10. Power input
11. Fuseholder
12. Microphone sensitivity rotary
control
13. Microphone
