and the device. If you lack these qualifications, do not attempt the installation yourself, but instead use a
professional structural rigger. Improper installation can result in bodily injury and or damage to property.
The device has to be installed out of the reach of people.
If the device shall be lowered from the ceiling or high joists, professional trussing systems have to be used.
The device must never be fixed swinging freely in the room.
Caution: Devices in hanging installations may cause severe injuries when crashing down! If you have
doubts concerning the safety of a possible installation, do NOT install the device!
Before rigging make sure that the installation area can hold a minimum point load of 10 times the device's
weight.
Mount the device to your trussing system using appropriate clamps.
For overhead use, always install an appropriate safety bond.
You must only use safety bonds and quick links complying with DIN 56927, shackles complying with DIN EN
1677-1 and BGV C1 carbines. The safety bonds, quick links, shackles and the carbines must be sufficiently
dimensioned and used correctly in accordance with the latest industrial safety regulations (e. g. BGV C1,
BGI 810-3).
Please note: for overhead rigging in public or industrial areas, a series of safety instructions have to be
followed that this manual can only give in part. The operator must therefore inform himself on the current
safety instructions and consider them.
The manufacturer cannot be made liable for damages caused by incorrect installations or insufficient safety
precautions!
Pull the safety bond through the stand sleeve and over the trussing system or a safe fixation spot. Insert the
end in the quick link and tighten the safety screw.
The maximum drop distance must never exceed 20 cm.
A safety rope which already held the strain of a crash or which is defective must not be used again.
Before taking into operation for the first time, the installation has to be approved by an expert!

Mounting on a speaker system

For mobile use, the device may be placed on a speaker system.
1
On the speaker system, first loosen the fixation screws of the legs. Pull out the legs until the cross
struts stand at a 90° angle to the legs. Tighten the fixation screws of the legs.
2
Loosen the fixation screw on the stand sleeve of the device and install the fixture on the tube via the
holder. Tighten the fixation screw.
3
Caution! The load has to be installed in a balanced way. The carrying capacity of the speaker system
must never be exceeded. The speaker system must be set up in a stable way. Make sure all fixation
screws fit tight.

DMX-512 connection / connection between fixtures

The wires must not come into contact with each other, otherwise
Please note, the starting address depends upon which controller is being used.
Only use a stereo shielded cable and 3-pin XLR-plugs and connectors in order to connect the controller with
the fixture or one fixture with another.
DANGER TO LIFE!
the fixtures will not work at all, or will not work properly.
