1. Included items
1 x camera VTC-HDH322PWD
1 x cable adapter BNC socket/plug
1 x user manual

2. Installation

(Also see the pictures on the following pages.)
This camera is a compact camera in a vandal-proof and weather-proof housing, class IP-66.
It is suitable for wall or ceiling mounting and has been developed for CCTV applications.
You will find the technical data at the end of the manual.

2.1 Camera mounting

Make sure to fix the camera onto a solid basis which is capable to carry the weight of the
camera. Ensure that the camera is safely installed by using only suitable screws.

2.2 Power supply and monitor impedance

Only use a stabilised 12 V DC power supply unit with sufficient wattage (see chapter
"Technical specifications" for recommended power supply units).
Only approved cables should be used.
If a monitor is connected directly, the monitor impedance has to be set to 75 Ohm.
Verify the position of the switch in case the video picture is of poor quality.
Power supply and video output is illustrated in picture 1.
A cable adapter BNC socket/plug is included in the delivery which can be put onto the
additional video output, e.g. to connect a monitor during the camera installation phase in
case the regular cable has already been laid (picture 3).

2.3 Camera housing

Loosen the housing screws. Carefully twist off the housing from the camera module.
Improper handling of the appliance will invalidate the warranty.
2.4 White dome cover (optional) (picture 5)
If you prefer to have a white dome cover instead of the anthracite one, a white dome cover
CABD322W is optionally available. You can simply slip the white dome cover over the
anthracite one (no need to fix it with screws etc).
