Error Diagnosis - Ground Zero GZDSP 6-8X Anleitung

Error Control
No function PWR LED on?
signal wire no contact or broken
no audio signal from the head-unit
amplifier not switched on
No sound
(PWR LED on)
non operational source selected
activated >MUTE< function (User Interface)
adjusted level on optional remote control
unit too low
signal wire no contact or broken
no audio signal from the head-unit
balance or fader control of the head-unit not
Single channels
in center position
with no function
wrong setup of input and output mode
>GAIN< level too low or >Mute< function
(user interface) active
Impure sound,
incorrect stereo inverted phase of one or more speakers
reproduction
speaker overload
DSP input override (distortion)
Distorted sound
quality
head-unit output override (distortion)
amplifier override (clipping)
>GAIN< level too high
Increased
noise level head-unit creates noise
diverse power supplies or ground connection
signal wire no contact or broken
Car specific
head-unit defective
interferences
amplifier defective
audible through
DSP unit or amplifier mounted close to an
the audio system
automotive control unit
analog output of an OEM MOST head-unit
connected
*Note:
Use an optional car specific interface to connect the digital MOST audio signal directly
to the digital input of the GZDSP 6-8X

Error diagnosis

Help / Solution
-check the fusing
-check the remote wire
-check the +12 Volt connection and wire
-check the ground connection and wire
-check the contact or replace the wire
-check the audio output signal of the head-unit
-check the remote out of the DSP (page 5)
-check the amplifiers power supply
-check the setting (page15)
-check the setting (page15)
-check the setting (page7)
-check the contact or replace the wire
-check the audio output signal of the head-unit
-check the setting of the head-unit
-check the setting (pages 11~14)
-check the setting (page 15)
-check the polarity of the speaker connection
-check the polarity of the high-level input (page 6)
-check the >PHASE< setting (page 15)
-check the >TIME ALIGNMENT< adjustment (page 16)
-reduce the volume level
-check the highpass filter and slope (page 15)
-select the correct input mode
-pay attention to the input sensitivity of the DSP unit (page 18)
-reduce the volume level of the head-unit
-set the sound controls of the head-unit to center position
-deactivate the >Loudness< function of the head-unit
-check the amplifiers input sensitivity
-reduce the level
-reduce the >GAIN< level (page 15)
-select a superior quality head-unit
-use the optical output (if available)
-let the audio store or manufacturer check the head-unit
-the head-unit, the DSP and each amplifier should be wired up to
a common ground and +12 Volt connection
-check the contact or replace the wire
-let the audio store or manufacturer check the head-unit
-let the audio store or manufacturer check the amplifier
-choose another mounting position
-connect the digital MOST audio signal directly to the DSP unit*
