Feature List - Ground Zero GZDSP 6-8X Anleitung

SIGNAL PROCESSOR
•
8-channel signal processor (DSP) - Cirrus Logic single core 32-bit/192 kHz
•
6-channel line input (RCA)
•
6-channel high-level input (with auto-on function)
•
AUX input (3.5 mm socket)
•
TOSLINK input (sampling rate up to 24-bit/96kHz)
•
8-channel line output (RCA)
•
Simple handling, one page graphical user interface (Windows compatible)
•
Realtime setup of all functions (via PC)
•
Channel separated parametric equalizer (6x 31 band / 2x 11band)
•
Channel separated time alignment (0-15 ms / 0-510 cm)
•
Adjustable crossover (HPF / LPF / BPF) in the range of 20 Hz to 20 kHz
•
Selectable crossover slope (6 to 48 dB/Oct)
•
Selectable phase shift for each channel (0˚ or 180°)
•
Time alignment – adjustable range 0 - 15 ms / 0 - 510 cm
•
Adjustable filters (Butterworth) HPF / LPF / BPF with a slope of 6 – 48 dB/Oct.
•
Selectable phase shift on each channel (0˚ or 180°)
•
Memory for 10 user presets (selectable with optional remote control)
• Optional remote-control unit available (GZDSP Remote) to adjust main and subwoofer level,
select the preset and input mode
•
LED power indicator
