File Dropdown Menu; Preset Memory Saving - Ground Zero GZDSP 6-8X Anleitung

*Important: The 10 presets can be used if the optional remote control GZDSP Remote is connected. Without the
remote-control unit, it is only possible to use and edit the last preset that has been saved.
Click „Select Save Place" and choose one of the
presets.
Confirm by clicking „Save to Flash"
*Note: All presets must be covered in numerical order
(Pos 1>Pos 2>Pos 3>...) without skipping a position,
otherwise it will not be possible to access the following
presets.
*Important: The 10 presets can be used if the optional remote control GZDSP Remote is connected. Without the
remote-control unit, it is only possible to use and edit the last preset that has been saved.

FILE dropdown menu

PC Contrl
Open
Save
Save as
Factory setting
Class-D AMP Setting
Write to Device*
Read from Device*
Exit

Preset memory saving

- 18 -
Opens the „Select COM" window (page 9)
Opens a setup file that has been saved previously to the PC memory
or an external drive
Saves the current setup as a file to the PC with unmodified filename. If
no filename has been selected yet, the dialogue will ask for the input.
Saves a setup file with a certain filename.
Sets the unit to default settings
No function
Saves the current setting to the preset memory of the GZDSP 6-8X unit.
At the following window, the preset number can be selected.
Opens one of the available presets from the memory of the
GZDSP 6-8X. The preset can be selected from the following window.
The blue frame indicates the actually selected preset number.
Closes the DSP software
