GZDSP 6-8X offers various system configurations. Here is a description of the two most common applications:
Input Mode
Output Mode
A/B
C/D
Channel
E /F
G/H
Note: The final crossover points depend on the speaker´s capacity that have been installed. The technical specifications
of the speakers will supply more information about possible applications and suggested crossover points.
Above, these are just noncommittal examples. Ground Zero will not be legally responsible for any kind of damage of
speakers or other components caused by wrong settings.

Application examples

3-way front system + subwoofer
(full active)
4 channel input (4CH)
Output Mode 5
Tweeter
Highpass filter
HP: 2500 – 6000 Hz
Midrange
Bandpass filter
HP: 150 – 300 Hz
LP: 2500 – 6000 Hz
Woofer
Bandpass filter
HP: 60 – 80 Hz
LP: 150 – 300 Hz
Subwoofer
Bandpass filter
HP: 10 – 30 Hz
LP: 50 – 100 Hz
2-way front system (active) +
2-way or coaxial rear system (passive)
+ subwoofer
6 channel input (6CH)
Output Mode 1
Tweeter
Highpass filter
HP: 2500 – 4500 Hz
Midwoofer
Bandpass filter
HP: 60 – 80 Hz
LP: 2500 – 4500 Hz
Rear system
Highpass filter
HP: 60 – 80 Hz
Subwoofer
Bandpass filter
HP: 10 – 30 Hz
LP: 50 – 100 Hz
- 19 -
