Assembly and Operating Instructions
Switch the VC120 on as follows:
PE
N
L1
Note
The VC120 must not be connected to a mains sock‐
et.
Ensure that there is optimal radio reception.
Check the direction of rotation of the tubular drive. If
the direction of rotation is incorrect, connect the
brown wire to Neutral.
24
Check the
rotation
of the tubular drive. If
the direction of rotation is
incorrect, connect the brown
wire to Neutral.
PE
N
L1
Mains 230V / 50 Hz
direction of
Mains 230V / 50 Hz
