For U.K. customers
If the socket outlets in the home are not suitable for the plug
supplied with this appliance, it should be cut off and an
appropriate 3 pin plug fitted. For details, refer to the
instructions described below.
Note: The plug severed from the mains lead must be
destroyed, as a plug with bared flexible cord is hazardous if
engaged in a live socket outlet.
SPECIAL INSTRUCTIONS FOR U.K. MODEL
IMPORTANT:
THE WIRES IN MAINS LEAD ARE COLOURED IN
ACCORDANCE WITH THE FOLLOWING CODE:
Blue: NEUTRAL
Brown: LIVE
As the colours of the wires in the mains lead of this
apparatus may not correspond with the coloured
markings identifying the terminals in your plug, proceed
as follows: The wire which is coloured BLUE must be
connected to the terminal which is marked with the letter
N or coloured BLACK. The wire which is coloured
BROWN must be connected to the terminal which is
marked with the letter L or coloured RED. Make sure that
neither wire is connected to the earth terminal of a three
pin plug.
Information for Users on Collection and Disposal of Old
Equipment
This symbol on the products, packaging,
and/or accompanying documents means
that used electrical and electronic products
should not be mixed with general
household waste.
For proper treatment, recovery and
recycling of old products, please take them
to applicable collection points, in
accordance with your national legislation
and the Directives 2002/96/EC.
By disposing of these products correctly,
you will help to save valuable resources
and prevent any potential negative effects
on human health and the environment
which could otherwise arise from
inappropriate waste handling.
For more information about collection and
recycling of old products, please contact
your local municipality, your waste
disposal service or the point of sale where
you purchased the items.
[Information on Disposal in other
Countries outside the European Union]
This symbol is only valid in the European
Union. If you wish to discard these items,
please contact your local authorities or
dealer and ask for the correct method of
disposal.
Taking care of the speaker
To maintain the spotless glossy surface of the polished
finish, wipe it with a soft, dry cloth. To avoid damage to the
finish, do not apply chemical solvents, such as alcohol,
benzine, thinner, insecticide, etc. Also, do not use a damp
cloth, or any type of cloth that contains chemical solvents,
or place a plastic or vinyl sheet on top of the speaker.
Otherwise, the finish may peel, the color may fade, or the
sheet may stick to the surface.
CONTENTS
ADVANCED YAMAHA ACTIVE SERVO
TECHNOLOGY II .........................................................1
Twisted Flare Port...........................................................1
FEATURES......................................................................2
SUPPLIED ACCESSORY..............................................2
PLACEMENT .................................................................2
Subwoofer orientation.................................................2
CONTROLS AND THEIR FUNCTIONS .....................3
CONNECTIONS.............................................................5
1 Connecting to line output (pin jack) terminal(s)
of the amplifier.......................................................5
2
Connecting to speaker output terminals
of the amplifier.......................................................7
Connecting to the INPUT1/OUTPUT terminals of the
subwoofer ....................................................................9
System connections ..................................................10
Plugging the subwoofer into an AC outlet ......................10
AUTOMATIC POWER-SWITCHING FUNCTION .........10
Setting the AUTO STANDBY switch ......................10
ADJUSTING THE BALANCE....................................11
Subwoofer frequency characteristics ........................13
TROUBLESHOOTING................................................14
SPECIFICATIONS .......................................................15
