Element
T19
T20
T21
T22
T23
T24
T25
T26
T27
T28
T29
T30
T31
T32
T33
5. DEVICE SETTINGS AND TESTS
There are a few settings and tests which can be carried out directly with Mixage without the need
for a computer. In the following a few points will be explained more thoroughly.
28
Function
Play/Pause Button
Starts and pauses the track's playback respec-
tively.
TRAX Encoder (Tracklist Navigation)
- By turning the encoder it is possible to scroll
through the track list.
- By pressing the encoder browser view will be
maximized.
Track Load Button
Assigns the selected track to the deck.
High Dial
Regulates the high EQ.
Mid Dial
Regulates the mid EQ.
Low Dial
Regulates the bass EQ.
Cue Button
By pressing one of the Cue Buttons the mo-
nitoring function for the selected deck will be
activated.
Linefader
Regulates the respective channel's volume.
Master Volume Dial (analog, not software)
The dial adjusts the master output's volume.
Phones Dial (analog, not software)
The dial adjusts the headphones' volume.
Cue Mix Fader
With the Cue Mix Fader it is possible to simu-
late a pre-mix via the headphones. In the right
position the master signal is audible, in the left
position the cue signal is audible.
Power Status LED
Illuminated when the controller is turned on, if
voltage is provided.
MIDI Status LED
Illuminated when MIDI signals are sent.
Master Level LED Indicator
Optically displays the master output level.
Crossfader
Crossfader between ch.1 and ch.2
Function with activated Shift -T3-
Cue 4 Button
Sets and triggers the 4th cue
point.
TRAX Encoder (Folder Navigation)
- By turning the encoder it is possi-
ble to navigate through the folders.
Load Button
Open folder [L], close folder [R]
Cue Button
Track Pre-Listen Play [L] / Stop
[R]
